Overview

VAKI Wellboat Channel Counter

The VAKI Wellboat Channel Counter is particularly useful during splitting and grading operations, as it provides critical data on the number of fish in each size group.
This data allows commercial aquaculture operators to gain key insights upon which they can base ongoing feed planning. The Wellboat Channel Counter also provides
a documented counting report and it records images of the actual count for future validation.

The B-Type

Wellboat Counters English

The Y-Type

Wellboat Counters English

Features

• Accurate counting of fish from 50g
• In special configuration it is possible to count smolt
• Capacity up to 300,000 smolts per hour
• Counting reports for every delivery
• Images are stored for verification of the count
• Measurement of average weight & size distribution
• Counting width from 1300 to 2000mm depending on type
• Automatic leveling system
• Excessive dewatering from vacuum pumps
• Full control from the bridge
• Gentle handling of fish
• Can be connected to VAKI cloudipsum

Name of file

Maintenance

• Trained agents for installation
• Repair service at each main area
• Critical Spares in place with main agents
• Routine Service contracts from distributors
• Updated Service / operating manual
• All units fully tested for hardware
• & software performance before delivery
• 2 years Warranty guarantee
• Customer service & back up

Name of file

Specifications

2 standard widths
– 2,1m counting width
– 1,4m counting width
• Size range: 50 – 9000g
• Capacity: 200 – 300.000 fish/hour
• Accuracy: over 98%

FISH SPIECIES

The Wellboat Channel Counter is well suited for all kind of fish such as: salmon, cod, turbot, halibut, trout, tilapia, sea bass and bream.

Technology

THE COUNTING TECHNOLOGY

The counter uses VAKI computer vision technology originally developed for counting fry, smolts and juvenile fish. Fish pass over a light source where an imaging line scanning camera is used to grab silhouette image of every single fish. The silhouettes are analyzed and used for counting and size estimation.

THE COUNTING SOFTWARE

The advanced software is used to count the fish as they pass the counting area. All fish images are stored and can be used for verifying the count. The screenshot to the right shows one second of smolt counting where the capacity is up to 100 fish per second.

Macro App

Among other features the Macro app provides the user the option to run the counter, view the results and email the count report from a smart phone or tablet.

Automatic Report Function

The automatic count report gives valuable and detailed information on the counting. The report can be supplied to the receiver of fish along with the counting file containing the images of all the fish. The throughput chart shows the rate of fish passing thru the counter. With this information the quality of the count can be assessed by checking for any overload.

Size Estimation

The average weight and the size distribution of the counted fish are showon a graph along with information on the total biomass of the fish.

Name of file
Name of file

Testimonials

Since we have incorporated the Macro Counter into our system, we have been able to improve inventories to within 2 to 3% accuracy. I would recommend VAKI’s equipment to any large fish farming aquaculture operation. George Slim Pacific Aquaculture

Goerge Slim

Pacific Aquaculture

Since we have incorporated the Macro Counter into our system, we have been able to improve inventories to within 2 to 3% accuracy. I would recommend VAKI’s equipment to any large fish farming aquaculture operation. George Slim Pacific Aquaculture

Goerge Slim

Pacific Aquaculture

Since we have incorporated the Macro Counter into our system, we have been able to improve inventories to within 2 to 3% accuracy. I would recommend VAKI’s equipment to any large fish farming aquaculture operation. George Slim Pacific Aquaculture

Goerge Slim

Pacific Aquaculture
